Kenjer Coil Tubing tools
EXTENDED REACH TOOL
Further, Faster
Streamline your operations by introducing Kenjer’s new extended reach tool, the Krawler, into your BHA. In addition to producing oscillations axially along the length of tubing, the Krawler contains a proprietary device which also induces a gentle lateral vibration to further reduce friction near the bit.
Key Features
44.5” shoulder to shoulder length is amongst the shortest in the market
Ability to provide friction reduction both locally and along the length of coil
High flow rate capability
Krawler can be ran with our CT Shock Sub to provide enhanced friction reduction near the bit in challenging applications
9800’ Lateral Length 400’ uphill 4.5 bpm 2400 wob
GAS SEPARATOR
+ To stay connected, and get important updates from KenJer, click below to sign up for our newsletter:
Save time by eliminating nitrogen effectively
Streamline your operations by introducing Kenjer’s new Gas Separator tool, the N2Xpellor™, into your BHA. This new tool allows you to safely and effectively pump nitrogen through the toolstring and expelling it to the wellbore before it reaches your extended reach tool and motor. This new tool allows you to use nitrogen effectively without the drawback of damaging your tools that contain rubber components. Also, the new tool is unlike any other tool and the simple design has no moving parts and no need to have multiple nozzle sizes due to the performance of this tool.
Key Features
30” shoulder to shoulder length is amongst the shortest on the market
Ability to pull nitrogen out of the toolstring without lose of liquid through the ports
High flow rate capability for both liquids and gases
Jars and Intensifiers
The KENJER CTJ is a straight pull up and push down jarring tool that employs a combination of proven principles of hydraulics and mechanics. The KENJER CTJ allows the operator to easily and simply control the intensity of the jarring blows by varying the load. The jar can deliver a wide range of blows from low to very high impact and impulse forces. The KENJER CTJ is fully adjustable down-hole by varying the pull of the coiled tubing to fire up or slacken off to fire down. Cocking or resetting the KENJER CTJ is automatic once the desired impact is delivered, simply raise or lower the string to allow the proprietary metering mechanism to be reactivated. THE KENJER CTJ is again ready to deliver the next impact. There is no need to “Cool Down” the KENJER CTJ as its proprietary design allows the jar to maintain its temperature and pressure compensation at all times.
KEY FEATURES
Fully adjustable impacts by varying loads
Easily Bi-Directional/Single Direction
One of the shortest jars on the market
High Rotational Torque
Fishing/Open Hole/Re-entry
Custom Timing for multiple applications
Kenjer CT Jar can be ran with our Intensifiers
